Versa-Lok – Accent

A slimmed-down version of the Standard wall unit, Accent units measure 4 inches tall by 12 inches wide. They’re lighter than Standard units but engineered with the same high-strength, low-absorption concrete. Easily installed, Accent units draw minimal attention to the wall, saving the spotlight for pools, gardens, and other features of the surrounding landscape.

SKU: N/A Categories: ,

Description

A slimmed-down version of the Standard wall unit, Accent units measure 4 inches tall by 12 inches wide. They’re lighter than Standard units but engineered with the same high-strength, low-absorption concrete. Easily installed, Accent units draw minimal attention to the wall, saving the spotlight for pools, gardens, and other features of the surrounding landscape.

The maximum stable, unreinforced VERSA-LOK wall height in best conditions, may be lower depending on soil, site, and loading conditions (including terraces). Taller walls need geogrid soil reinforcement, designed by a qualified engineer. Check your local building code requirements. Please contact your supplier or VERSA-LOK representative for assistance.

Additional information

Size

Finishes

Standard, Weathered

Color

, ,

Shapes

Accent Unit

Accent Unit – Weathered Pattern

Dimensions

Width (face):12″ (304.8mm)
Width (rear):8″ (203.2mm)
Height:4″ (101.6mm)
Depth:12″ (304.8mm)
Face Area:0.33 ft2 (0.015m2)
Weight:36 lbs (16.33kg)
Weight / Face Area:109lbs/ft2 (1089kg/m2)
Setback:3/4″ or 1/4″ per unit
Batter/Cant:10.6 or 3.6 degrees
# Versa-Tuff Snap-off Pins:2 per unit
Minimum Radius:3ft
Max Unreinforced Height:4 ft*
Max Geogrid Reinforced
Height:50+ ft
